Position vector
In the coordinate system, the line joining the origin O to the point P in the system is called the position vector of Point P
OP= x
i+y
j+z
k
Vector joining two points in the Coordinate system
Let Point P and Q are there
Position Vector of Point P
OP= x
_{1} i+y
_{1} j+z
_{1}k
Position Vector of Point Q
OQ= x
_{2} i+y
_{2} j+z
_{2}k
Then Vector PQ is defined as
PQ=OQ-OP
=(x
_{2} -x
_{1})
i +(y
_{2} -y
_{1})
j +(z
_{2} -z
_{1})
k
Concept Map's for Position and displacement in two dimensional motion
2.Average velocity
- Consider a particle moving along a curved path in x-y plane shown below in the figure
- Suppose at any time,particle is at the point P and after some time 't' is at point Q where points P and Q represents the position of particle at two different points.
- Position of particle at point P is described by the Position vector r from origin O to P given by
r=xi+yj
where x and y are components of r along x and y axis
- As particle moves from P to Q,its displacement would be would be Δr which is equal to the difference in position vectors r and r'.Thus
Δr = r'-r = (x'i+y'j)-(xi+yj) = (x'-x)i+(y'-y)j = Δxi+Δyj (1)
where Δx=(x'-x) and Δy=(y'-y)
- If Δt is the time interval during which the particle moves from point P to Q along the curved path then average velocity(v_{avg}) of particle is the ratio of displacement and corresponding time interval
since v_{avg}=Δr/Δt , the direction of average velocity is same as that of Δr
- Magnitude of Δr is always the straight line distance from P to Q regardless of any shape of actual path taken by the particle.
- Hence average velocity of particle from point P to Q in time interval Δt would be same for any path taken by the particle.
3.Instantaneous velocity
- We already know that instantaneous velocity is the velocity of the particle at any instant of time or at any point of its path.
- If we bring point Q more and more closer to point P and then calculate average velocity over such a short displacement and time interval then
where v is known as the instantaneous velocity of the particle.
- Thus, instantaneous velocity is the limiting value of average velocity as the time interval approaches zero.
- As the point Q approaches P, direction of vector Δr changes and approaches to the direction of the tangent to the path at point P. So instantaneous vector at any point is tangent to the path at that point.
- Figure below shows the direction of instantaneous velocity at point P.
- Thus, direction of instantaneous velocity v at any point is always tangent to the path of particle at that point.
- Like average velocity we can also express instantaneous velocity in component form
where v_{x} and v_{y} are x and y components of instantaneous velocity.
- Magnitude of instantaneous velocity is
|v|=√[(v_{x})^{2}+(v_{y})^{2}]
and angle θ which velocity vector makes with x-axis is
tanθ=v_{x}/v_{y}
- Expression for instantaneous velocity is
Thus, if expression for the co-ordinates x and y are known as function of time then we can use equations derived above to find x and y components of velocity.
4. Average and instantaneous acceleration
- Suppose a particle moves from point P to point Q in x-y plane as shown below in the figure
- Suppose v_{1} is the velocity of the particle at point P and v_{2} is the velocity of particle at point Q
- Average acceleration is the change in velocity of particle from v_{1} to v_{2} in time interval Δt as particle moves from point P to Q. Thus average acceleration is
Average acceleration is the vector quantity having direction same as that of Δv.
- Again if point Q approaches point P, then limiting value of average acceleration as time approaches zero defines instantaneous acceleration or simply the acceleration of particle at that point. This, instantaneous acceleration is
- Figure below shows instantaneous acceleration a at point P.
- Instantaneous acceleration does not have same direction as that of velocity vector instead it must lie on the concave side of the curved surface.
- Thus velocity and acceleration vectors may have any angle between 0 to 180 degree between them.
Concept Map's for Velocity and acceleration in two dimensional motion
Question
The position of a object is given by
r= 3ti + 2t^{2}j+ 11k
Where t is in second and coefficients have the proper units for r to be in centimetres
a) Find v(t) and a(t) of the object
b) Find the magnitude and direction of the velocity at t=3 sec
Solution
It is given in the questions
r= 3ti + 2t^{2}j+ 11k
Now
v(t) = dr/dt
Therefore,
v(t) =d[3ti + 2t^{2}j+ 11k ]/dt =3i +4tj
Now
a(t) = dv/dt
Therefore,
a(t) =d[3i +4tj]/dt =4j
So acceleration is 4 cm/s^{2} across y-axis
Now velocity at 3 sec
v(t) =3i +4tj=3i +12j
So its magnitude is √(3^{2} +12^{2}) = 12.4 cm/s
And direction will be tan^{-1}(v^{y}/v^{x}) =tan^{-1}(4) =76^{0}
